50Hz 12kW 15kVA Diesel Generator with Perkins 403A-15G2 Engine
Introduction
The GENLITEC POWER GPP15D5 / GPP15S5 is a 12KW/15KVA prime and 13.2KW/16.5KVA standby diesel generator set designed for reliable 50Hz power generation. Operating at 1500 RPM, it supports 220/380V, 230/400V and 240/415V voltage configurations for a wide range of three-phase power applications.
Powered by a Perkins 403A-15G2 3-cylinder diesel engine and matched with a 12.8KW/16KVA alternator, the GPP15D5 open type and GPP15S5 silent type generator sets provide dependable prime, standby and backup power for commercial buildings, industrial facilities, construction sites, agricultural facilities, telecommunications and other critical power applications.
Generator Set
| Open Type Model | GPP15D5 |
| Silent Type Model | GPP15S5 |
| Prime Power | 12KW/15KVA |
| Standby Power | 13.2KW/16.5KVA |
| Phase & Wires | 3 Phase, 4 Wires |
| Power Factor | 0.8 |
| Frequency | 50Hz |
| Rated Voltage | 220/380V; 230/400V; 240/415V |
| Rated Speed | 1500 RPM |
| Fuel Tank Capacity | 50L |
Diesel Engine
| Engine Model | Perkins 403A-15G2 |
| Number of Cylinders | 3 |
| Prime Power | 14kW @ 1500RPM |
| Standby Power | 15kW @ 1500RPM |
| Aspiration | Naturally Aspirated |
| Combustion System | Indirect Injection |
| Governor | Mechanical |
| Cooling System | Water Cooled |
| Bore × Stroke | 84 × 90 mm |
| Displacement | 1.496L |
| Compression Ratio | 22.5:1 |
| Rated Speed | 1500 RPM |
| Starting System | DC 12V |
| Lubrication Capacity | 6L |
| Coolant Capacity | 6L |
Fuel Consumption
| 100% Prime Load | 4.3 L/h |
| 75% Prime Load | 3.1 L/h |
| 50% Prime Load | 2.2 L/h |
| 25% Prime Load | 1.5 L/h |
| Standby Power | 5.0 L/h |
Alternator
| Rated Power | 12.8KW/16KVA |
| Number of Phase | 3 |
| Frequency | 50Hz |
| Power Factor | 0.8 |
| Poles | 4 |
| Temperature Rise | 125K |
| Terminals | 6/12 |
| Insulation Class | H Class |
| Ambient Temperature | 40℃ |
| IP Rating | IP23 |
| Excitation System | Self-Excited |
| Bearing | Single Bearing |
| Coating | Vacuum Impregnation |
| Voltage Regulator | A.V.R |
| Coupling | Flexible Disc |
Control Panel
| ○ Emergency stop button | ○ Main circuit breaker |
| ○ Float battery charger | ○ Manual/Auto start control panel |
| ○ Fuel level meter | ○ Controller power switch |
| ○ Alarm buzzer |
Sound Attenuated Enclosure
○ Weatherproof sound-attenuated enclosure with internal exhaust silencer
○ Corrosion-resistant construction for outdoor installation
○ Available for GPP15S5 silent type generator set
Options
○ ATS for automatic start and stop when utility power fails or returns
○ Remote monitoring system
○ Single axle trailer
○ 24-hour fuel tank
○ 48-hour fuel tank
○ Power sockets, including CEE or AUS standards
Applications
The GENLITEC POWER 12KW/15KVA diesel generator set is suitable for a wide range of prime, standby and backup power applications, including:
○ Commercial and office buildings
○ Industrial facilities
○ Construction and job sites
○ Agricultural and rural facilities
○ Telecommunication and remote sites
○ Emergency and standby power systems
Why Choose GENLITEC POWER
GENLITEC POWER diesel generator sets are designed to provide dependable power, practical configuration and reliable performance for a wide range of applications.
○ Perkins diesel engine for reliable and efficient power generation
○ Prime and standby power configurations for different operating requirements
○ Multiple voltage configurations available
○ Open and silent type configurations available
○ Suitable for commercial, industrial and backup power applications
○ Factory-direct supply with customized generator set solutions
For more information, please visit the GENLITEC POWER® Why Choose GENLITEC POWER page.
Warranty
GENLITEC POWER provides a standard warranty of 12 months or 1000 working hours, whichever comes first. For details, please refer to the GENLITEC POWER® Warranty Policy.
