DE165GC Standby 165KVA Caterpillar Diesel Generator
Short Description
Producing 165 kVA of reliable power at 50 Hz, the CATERPILLAR DE165 GC diesel generator set is designed to meet ISO 8528-5 transient response requirements.
- ModelCATERPILLAR DE165GC
- Prime Power (PRP)N/A
- Standby Power (ESP)132kW/165kVA
- EngineC7.1
- Fuel consumption (100%)5.1L/H
Product Details
Product Tags
Video
Introduction
The Caterpillar DE165 GC diesel generator set provides 165kVA/132kW standby power for commercial, industrial, construction, agricultural and backup power applications. Designed for 50Hz operation, the generator set delivers stable three-phase power with a 380~415V rated voltage and 0.8 power factor.
Powered by a Caterpillar C7.1 inline four-cylinder, four-stroke diesel engine, the DE165 GC features turbocharged, air-to-air charge cooled induction, inline fuel injection and a mechanical governor. The generator set is equipped with a CATERPILLAR GCCP1.1 control panel, ABB main circuit breaker and a weatherproof sound attenuated enclosure with an internal exhaust silencer.
Generator Set
| Genset Model | DE165 GC |
| Standby Power | 165kVA / 132kW |
| Phase & Wire | 3 Phase, 4 Wires |
| Power Factor | 0.8 |
| Frequency | 50Hz |
| Rated Voltage | 380~415V |
Diesel Engine
| Engine Model | CAT C7.1 Inline 4-Stroke Diesel |
| Bore x Stroke | 105 x 135 mm |
| Displacement | 7.0L |
| Compression Ratio | 16.0:1 |
| Aspiration | Turbocharged, Air to Air Charge Cooled |
| Fuel Injection System | Inline |
| Governor Type | Mechanical |
Fuel Consumption
| 100% Load with Fan | 35.1L/H |
| 75% Load with Fan | 27.2L/H |
| 50% Load with Fan | 18.3L/H |
Control Panel
| ○ Emergency stop button | |
| ○ ABB brand Main circuit breaker | |
| ○ CATERPILLAR GCCP1.1 control panel |
Sound Attenuated Enclosure
○ Fully weatherproof sound attenuated enclosure with internal exhaust silencer
○ Highly corrosion resistant construction
Applications
The Caterpillar DE165 GC 165kVA diesel generator set is suitable for a wide range of standby and backup power applications, including:
○ Commercial buildings
○ Industrial facilities
○ Construction sites
○ Agricultural facilities
○ Telecommunication facilities
○ Emergency and backup power applications
Why Choose GENLITEC POWER
GENLITEC POWER provides diesel generator sets and mobile lighting towers for construction, mining, telecommunications, infrastructure, industrial, commercial and other demanding applications. We offer flexible configurations, international engine and alternator brands, customized power solutions, technical support and after-sales service.
○ Diesel generator sets and mobile lighting towers from one supplier
○ Multiple engine, alternator and controller brand options
○ Customized power solutions for different applications
○ Professional manufacturing and quality control
○ International export and project experience
○ Technical support and after-sales service
For more information, please visit the GENLITEC POWER® Why Choose GENLITEC POWER page.
Warranty
GENLITEC POWER provides a standard warranty of 12 months or 1000 working hours, whichever comes first. For details, please refer to the GENLITEC POWER® Warranty Policy.
Frequently Asked Questions
What is the rated power of the Caterpillar DE165 GC?
The Caterpillar DE165 GC provides 165kVA / 132kW standby power at 50Hz.
What diesel engine is used in the DE165 GC?
The generator set is powered by a Caterpillar C7.1 inline four-stroke diesel engine with turbocharged, air-to-air charge cooled aspiration, inline fuel injection and a mechanical governor.
What are the rated voltage and frequency?
The DE165 GC is designed for 50Hz operation with a rated voltage of 380~415V and three-phase, four-wire configuration.
What control panel is installed?
The generator set is equipped with a CATERPILLAR GCCP1.1 control panel, an ABB main circuit breaker and an emergency stop button.
What is the fuel consumption of the DE165 GC?
Fuel consumption with fan is approximately 35.1L/H at 100% load, 27.2L/H at 75% load and 18.3L/H at 50% load.
What is the warranty period?
GENLITEC POWER provides a standard warranty of 12 months or 1000 working hours, whichever comes first.
