250KVA Perkins Diesel Generator-50Hz

250KVA Perkins Diesel Generator-50Hz
  • 250KVA Perkins Diesel Generator-50Hz
  • 250KVA Perkins Diesel Generator-50Hz
  • 250KVA Perkins Diesel Generator-50Hz
  • 250KVA Perkins Diesel Generator-50Hz

Short Description:

GENLITEC POWER® GPP250D5 (open type), GPP250S5 (silent type) diesel generator set powered by original PERKINS 1206A-E70TTAG3, with prime power 200KW/250KVA, standby power 220KW/275KVA....


  • Open Type Model: GPP250D5
  • Silent Type Model: GPP250S5
  • Engine: PERKINS 1206A-E70TTAG3
  • Prime Power: 200KW/250KVA
  • Standby Power: 220KW/275KVA

Product Details

Product Tags



GENLITEC POWER® 200KW/250KVA PERKINS DIESEL GENERATOR SET FEATURES

○ Brand new original PERKINS 1206A-E70TTAG3 water cooled diesel engine

○ Original STAMFORD, LEROY SOMER or GENLITEC POWER® single bearing 100% copper brushless alternator

○ Rating 220/380V, 3-Phase 4-Wires, 50Hz, 1500RPM, 0.8PF, IP23, H insulation class

○ 50℃ radiator with engine driven fan mounted on the based frame

○ Set mounted control panel equipped with DEEPSEA, COMAP, DEIF or SMARTGEN digital controller

○ Original ABB, DELIXI or CHINT brand MCCB type main circuit breaker

○ Diesel engine and alternator mounted on a based frame with anti-vibration mountings

○ 24V DC electric start system with free-maintenance lead-acid battery and float battery charger

○ Industrial silencers with blexible connects and elbow

○ Complete engine alarm system

○ CE, ISO 9001:2015 approved


● GENERATOR SET

Open Type Model GPP250D5
Silent Type Model GPP250S5
Prime Power 200KW/250KVA
Standby Power 220KW/275KVA
Phase & Wires 3 Phase, 4 Wires
Power Factor 0.8
Frequency 50Hz
Rated Voltage 220/380V, 230/400V, 240/415V
Fuel Tank Capacity 380L

● DIESEL ENGINE


Engine Model PERKINS 1206A-E70TTAG3
Cylinder Number 6
Aspiration System Turbocharged Aftercooled
Cooling System Water Cooled
Governor Type Electronic ECM
Bore x Stroke 105 x 135 mm
Compression Ratio 15.8:1
Rated Speed 1500RPM
Displacement 7.01L
Rated Power 222KW
Standby Power 244KW
Coolant Capacity 25L
Oil Capacity 16L (Max.)
Combustion System Common Rail
Electric Starting System DC 24V

● FUEL CONSUMPTION

100% Prime Load 56.9L/H
75% Prime Load 41.5L/H
50% Prime Load 28.1L/H
25% Prime Load 15.4L/H

ALTERNATOR


Number of Phase 3
Rated Power 200KW/250KVA
Frequency 50Hz
Power Factor 0.8
Poles 4
Temp. Rise 125K
Terminals 12
Insulation Class H
Ambient Temp. 40℃
IP Rating IP23
Excitation System Self-Excited
Bearing Single Bearing
Coating Vacuum Impregnation
Voltage Regulator A.V.R
Coupling Flexible Disc

CONTROL PANEL

Emergency stop button

Main circuit breaker

Float baterry charger

Manual/Autostart control panel

Fuel level meter

Controller power switch

Alarm buzzer


SOUND ATTENUATED ENCLOSURE

Fully Weatherproof Sound Attenuated Enclosure With Internal Exhaust Silencer

Highly Corrosion Resistant Construction


WARRANTY

12 months or 1000 working hours, whichever comes first


OPTIONS

ATS Panel (for automatic start & stop when electricity power off & on)

Heater

12 hours fuel tank

24 hours fuel tank

Power Sockets (CEE or AUS standard)

Remote & Mornitoring System (4G or Wifi)

Sychronization Panel
