Short Description:

GENLITEC POWER® GPC150D5 (open type), GPC150S5 (silent type) diesel generator sets powered by original CUMMINS diesel engine 6BTAA5.9-G12, with prime power 120kw/150kva and standby power 132kw/165kva....


  • Model: GPC150D5 | GPC150S5
  • Engine: CUMMINS 6BTAA5.9-G12
  • Prime Power: 120KW/150KVA
  • Standby Power: 132KW/165KVA
  • Voltage: 220/380V | 230/400V | 240/415V

Product Details

Product Tags

Product Video


GENLITEC POWER® 120KW/150KVA CUMMINS DIESEL GENERATOR SET FEATURES

○ Brand new original CUMMINS brand water cooled diesel engine

STAMFORD, LEROY SOMER or GENLITEC POWER® single bearing 100% copper brushless alternator

Rating 220/380V, 3-Phase, 50Hz, 1500RPM, 0.8PF, IP23, H insulation class

50℃ radiator with engine driven fan mounted on the based frame

Set mounted control panel equipped with DEEPSEA, COMAP, DEIF or SMARTGEN digital controller

Original ABB, DELIXI or CHINT brand MCCB type main circuit breaker

Diesel engine and alternator mounted on a based frame with anti-vibration mountings

24V DC electric start system with free-maintenance lead-acid battery and float battery charger

Industrial silencers with blexible connects and elbow

Complete engine alarm system


● GENERATOR SET

Open Type Model GPC150D5
Silent Type Model GPC150S5
Prime Power 120KW/150KVA
Standby Power 132KW/165KVA
Phase & Wire 3 Phase, 4 Wires
Power Factor 0.8
Frequency 50Hz
Voltage 220/380V; 230/400V; 240/415V

● DIESEL ENGINE


Model CUMMINS 6BTAA5.9-G12
Cylinder 6 In-Line
Aspiration System Turbocharged, Air to Air Cooling
Cooling Method Water Cooled
Governor Type Electronic
Bore x Stroke 102 x 120 mm
Compression Ratio 17.3:1
Rated Speed 1500 RPM
Displacement 5.9 L
Rated Power 140 KW
Fuel System P7100 Type
Oil Capacity 16.4 L
Coolant Capacity 29 L
Starter Motor Capacity DC 24V-40A

● FUEL CONSUMPTION

100% Prime Load 35 L/H
75% Prime Load 26 L/H
50% Prime Load 17 L/H
25% Prime Load 9 L/H

ALTERNATOR


Number of Phase 3
Rated Power 120KW/150KVA
Frequency 50 Hz
Power Factor 0.8
Poles 4
Temp. Rise 125K
Terminals 12
Insulation Type H Class
Ambient Temp. 40℃
IP Rating IP23
Excitation System Self-Excited
Bearing Single Bearing
Coating Vacuum Impregnation
Voltage Regulator A.V.R
Coupling Flexible Disc

CONTROL PANEL


Emergency stop button

Main circuit breaker

Float baterry charger

Manual/Autostart control panel

Fuel level meter

Controller power switch

Alarm buzzer


● GENLITEC POWER A-TYPE SOUND ATTENUATED ENCLOSURE


Fully Weatherproof Sound Attenuated Enclosure With Internal Exhaust Silencer

Highly Corrosion Resistant Construction


WARRANTY

12 months or 1000 working hours, whichever comes first


OPTIONS

ATS Panel (for automatic start & stop when electricity power off & on)

12 hours fuel tank

24 hours fuel tank

Power Sockets (CEE or AUS standard)

○ 4G/Wifi Remote & Monitoring System
