Short Description:

GENLITEC POWER® GPP200D6 (open type), GPP200S6 (silent type) diesel generator set powered by original PERKINS 1106A-70TAG3, with prime power 160KW/200KVA standby power 176KW/220KVA....


  • Open Type Model: GPP200D6
  • Silent Type Model: GPP200S6
  • Engine: PERKINS 1106A-70TAG3
  • Prime Power: 160KW/200KVA
  • Standby Power: 176KW/220KVA

Product Details

Product Tags


GENLITEC POWER® 160KW/200KVA PERKINS DIESEL GENERATOR SET FEATURES

○ Brand new original PERKINS 1106A-70TAG3 water cooled diesel engine

○ Original STAMFORD, LEROY SOMER or GENLITEC POWER® single bearing 100% copper brushless alternator

○ Rating 127/220V, 3-Phase 4-Wires, 60Hz, 1800RPM, 0.8PF, IP23, H insulation class

○ 50℃ radiator with engine driven fan mounted on the based frame

○ Set mounted control panel equipped with DEEPSEA, COMAP, DEIF or SMARTGEN digital controller

○ Original ABB, DELIXI or CHINT brand MCCB type main circuit breaker

○ Diesel engine and alternator mounted on a based frame with anti-vibration mountings

○ 24V DC electric start system with free-maintenance lead-acid battery and float battery charger

○ Industrial silencers with blexible connects and elbow

○ Complete engine alarm system

○ CE, ISO 9001:2015 approved


● GENERATOR SET

Open Type Model GPP200D6
Silent Type Model GPP200S6
Prime Power 160KW/200KVA
Standby Power 176KW/220KVA
Phase & Wires 3 Phase, 4 Wires
Power Factor 0.8
Frequency 60Hz
Rated Voltage 110/190V, 120/208V, 127/220V, 254/440V
Fuel Tank Capacity 300L

● DIESEL ENGINE


Engine Model PERKINS 1106A-70TAG3
Cylinder Number 6
Aspiratin System Turbocharged Aftercooled
Cooling Method Water Cooled
Governor Type Mechanical
Bore x Stroke 105 x 135 mm
Compression Ratio 16:1
Rated Speed 1800 RPM
Displacement 7.01L
Rated Power 180.5KW
Standby Power 199.7KW
Combustion System Direct Injection
Oil Capacity 16.5L
Coolant Capacity 21L
Electric Starting System DC 24V

● FUEL CONSUMPTION

100% Prime Load 46.5L/H
75% Prime Load 35.3L/H
50% Prime Load 22.7L/H
25% Prime Load 12.4L/H

ALTERNATOR


Number of Phase 3
Rated Power 160KW/200KVA
Frequency 60Hz
Power Factor 0.8
Poles 4
Temp. Rise 125K
Terminals 12
Insulation Class H
Ambinet Temp. 40℃
IP Rating IP23
Excitation System Self-Excited
Bearing Single Bearing
Coating Vacuum Impregnation
Voltage Regulator A.V.R
Coupling Flexible Disc

CONTROL PANEL

Emergency stop button

Main circuit breaker

Float baterry charger

Manual/Autostart control panel

Fuel level meter

Controller power switch

Alarm buzzer


SOUND ATTENUATED ENCLOSURE

Fully Weatherproof Sound Attenuated Enclosure With Internal Exhaust Silencer

Highly Corrosion Resistant Construction


WARRANTY

12 months or 1000 working hours, whichever comes first


OPTIONS

ATS Panel (for automatic start & stop when electricity power off & on)

Heater

12 hours fuel tank

24 hours fuel tank

Power Sockets (CEE or AUS standard)

Remote & Mornitoring System (4G or Wifi)

Sychronization Panel
