28KVA Cummins Diesel Generator-50Hz

28KVA Cummins Diesel Generator-50Hz
  • 28KVA Cummins Diesel Generator-50Hz
  • 28KVA Cummins Diesel Generator-50Hz
  • 28KVA Cummins Diesel Generator-50Hz
  • 28KVA Cummins Diesel Generator-50Hz
  • 28KVA Cummins Diesel Generator-50Hz

Short Description:

GENLITEC POWER® GPC28D5 (open type), GPC28S5 (silent type) Cummins diesel generator powered by original CUMMINS diesel engine 4B3.9-G1/G2, with prime power 22kw/28kva and standby power 24kw/30kva....


  • Open Type Model: GPC28D5
  • Silent Type Model: GPC28S5
  • Engine: CUMMINS 4B3.9-G1/G2
  • Prime Power: 22KW/28KVA
  • Standby Power: 24KW/30KVA

Product Details

Product Tags

Product Video


GENLITEC POWER® 22KW/28KVA CUMMINS DIESEL GENERATOR SET FEATURES

○ Brand new original CUMMINS 4B3.9-G1/G2 brand water cooled diesel engine

STAMFORD, LEROY SOMER or GENLITEC POWER® single bearing 100% copper brushless alternator

○ Rating 230/400V, 3-Phase, 50Hz, 1500RPM, 0.8PF, IP23, H insulation class

○ 50℃ radiator with engine driven fan mounted on the based frame

○ Set mounted control panel equipped with DEEPSEA, COMAP, DEIF or SMARTGEN digital controller

○ Original ABB, DELIXI or CHINT brand MCCB type main circuit breaker

○ Diesel engine and alternator mounted on a based frame with anti-vibration mountings

○ 24V DC electric start system with free-maintenance lead-acid battery and float battery charger

○ Industrial silencers with blexible connects and elbow

○ Complete engine alarm system


● GENERATOR SET

Open Type Model GPC28D5
Silent Type Model GPC28S5
Prime Power 22KW/28KVA
Standby Power 24KW/30KVA
Phase & Wire 3 Phase, 4 Wires
Power Factor 0.8
Frequency 50Hz
Rated Voltage 220/380V, 230/400V, 240/415V
Fuel Tank Capacity 40L

● DIESEL ENGINE


Engine Model CUMMINS 4B3.9-G1/G2
Cylinder Number 4
Aspiration System Naturally
Cooling Method Water Colled
Governor Type G1: Mechanical; G2: Electronic
Bore x Stroke 102 x 120 mm
Compression Ratio 17.5:1
Rated Speed 1500 RPM
Displacement 3.9L
Rated Power 24KW
Standby Power 27KW
Fuel System BYC A-Type
Oil Capacity 10.9L
Coolant Capacity 7.2L (Engine Only)
Electric Starting System DC 24V

● FUEL CONSUMPTION

100% Prime Load 6.7L/H
75% Prime Load 5.2L/H
50% Prime Load 4.0L/H
25% Prime Load 2.7L/H

ALTERNATOR


Number of Phase 3
Rated Power 22KW/28KVA
Frequency 50Hz
Power Factor 0.8
Poles 4
Temp. Rise 125K
Terminals 12
Insulation Class H
Ambient Temp. 40℃
IP Rating IP23
Excitation System Self-Excited
Bearing Single Bearing
Coating Vacuum Impregnation
Voltage Regulator A.V.R
Coupling Flexible Disc

CONTROL PANEL


Emergency stop button

Main circuit breaker

Float baterry charger

Manual/Autostart control panel

Fuel level meter

Controller power switch

Alarm buzzer


● GENLITEC POWER® A-TYPE SOUND ATTENUATED ENCLOSURE


Fully Weatherproof Sound Attenuated Enclosure With Internal Exhaust Silencer

Highly Corrosion Resistant Construction


WARRANTY

12 months or 1000 working hours, whichever comes first


OPTIONS

ATS (for automatic start & stop when electricity power off & on)

Single axle trailer

12 hours fuel tank

24 hours fuel tank

Power Sockets (CEE or AUS standard)
